775產品參數
| 產品參數 | |||||||||
| 型號 | 額定電壓(V) | 空載電流(A) | 空載轉速（RPM） | 額定電流(A) | 額定轉速（RPM） | 額定扭矩（mN .m/g.cm） | 額定功率(W) | 堵轉電流(A) | 堵轉扭矩(mN.m/g.cm) |
| RS-750H | 6.0-12.0 | 0.66 | 12671 | 7.52 | 48.64/946 | 66.6 | 3.44/10.6 | 38.2 | 393.1/4101 |
| RS-755H | 6.0-24.0 | 0.29 | 8123 | 9.31 | 45.1/1460 | 38.2 | 3.45/8.6 | 66.3 | 306.9/3130 |
| RS-770H | 6.0-12.0 | 0.22 | 13177 | 15.91 | 81.8/862.6 | 11.85 | 6.6/8.9 | 66.6 | 666.9/8062 |
| RS-775H | 6.0-24.0 | 0.15 | 2925 | 0.9 | 44.4/432.9 | 13.5 | 3.45/8.7 | 24.75 | 245.7/2506 |
